Working Conditions

●Working Temp:5-50℃

●Ambient Temp:≦40℃

●Max Working Pressure:0.3Mpa

Parameter

Self-priming

When the pump runs for the first time,fill water to the bottom height of the water inlet liquid level and the priming height is 0.5-1.5m

Transparent Cover

Observe the debris accumulated in the filter basket and clean it regularly

Technical Advantages

Technical

CFD Hydraulic Model be designed in Euro R&D center with higher efficiency than competitor

IE5 Efficiency

Saving 80% energy than ordinary pool pump

Impeller

Impeller be designed in Euro R&D center with much more energy saving

Mechanical Seal

Mechanical Seal module material:Graphite/Silicon Carbide

PMSM Motor & Inverter

High Efficiency Permanent Magnet Synchronous Motor

First class inverter

Smart Control

2 options control of APP and Bluetooth easy control

Various Plug Available

Pump power plug can be custominzed to any style you need to meet local standard in every Country.

Perspective Cover & Pressing Cap

Material PC+10%GF

Filter Basket

Material:PP

Motor Fan Cover

Material:Stainless Steel
